- Đàn KROME-61:
- Bàn Phím Semi Weighted
- Velocity sensitive
- Transpose
Âm Thanh
- Maximum Polyphony:
- 120 voices (120 Oscillators) / Single Mode
60 voices (120 Oscillators) / Double Mode
- Bộ nhớ PCM:
- 3.8 GB (In case of 48 kHz, 16-bit Linear PCM converted)
583 multisamples (including 12 Stereo multi-samples)
2,080 drumsamples (including 474 Stereo Drumsamples )
- EQ:
- Three bands, with sweepable mid
- Modulation:
- For each oscillator: two envelope generators (Filter & Amp)
Two LFOs
Two key tracking generators (Filter & Amp)
Two AMS mixers
Pitch EG
Common LFO
Two common key tracking generators
- Combination:
- Timbre Number:
- Max: 16
For each Timbre: keyboard and velocity split/layer/crossfades
Modifications to the program settings via the Tone Adjust function
- Master Keyboard Functionality:
- Krome can act as a Master Keyboard able to control external MIDI devices such as sound modules.
- Drum Kit:
- Stereo and mono drum samples
8 velocity zones switch (crossfades and layers)
- The number of Combination / Program / Drum Kit:
- User Combination
- 512 Combination (288 Preload)
- User Program
- 768 Program (640 Preload)
- User Drum Kit
- 48 Drum Kit (32 Preload)
- Preset Program
- 256 GM2 Program + 9 GM2 Drums Program
Hiệu Ứng
- Insert Effects
- 5 Insert Effects (stereo in/out)
- Master Effects
- 2 Master Effects (stereo in/out)
- Total Effects
- 1 Total Effect (stereo in/out)
- Timbre / Track EQ
- 3-band EQ per in 1 Timbre / in 1 Track
- Effect Types
- 193 types
(Usable as insert, master, or total effects. However, double-size effects cannot be used as a total effect.)
- Modulation
- Dynamic Modulation, 2 Common LFO
- Effects Control Busses
- Stereo side chain (Limiter, Gate, Vocoder, etc)
- Effect Preset
- 32 preset per effect
Điệu tự động thông minh:
- Program Mode:
- 1 unit
- Combination, Sequencer Mode:
- 2 units are available.
- Number of pattern:
- 5 preset Arpeggio pattern
- 1,028 User Arpeggio pattern (900 Preload)
Drum Track
- Preset Patterns
- 637 patterns
(Common with the preset pattern of the Sequencer mode)
- User Patterns
- 1,000 patterns
(Pattern created in Sequencer mode can be converted to drum track user pattern)
- Configurable “Trigger Mode / Sync / Zone”
Thu âm
- Tracks
- 16-track MIDI Sequencer + 1 master track
- Number of Songs
- 128 Songs
- Resolution
- 1/480
- Tempo
- 40.00 – 300.00 (1/100 BPM resolution)
- Maximum memory
- 210,000 MIDI events
- Template Song
- 16 preset / 16 user template songs
- Cue List function
- 20 Cue List
Songs can be arranged consecutively or repeatedly in up to 99 steps, a cue list can be converted back into a song.
- Pattern / RPPR (Realtime Pattern Play and Recording)
- 637 Preset / 100 User pattern (Per song)
1 pattern set per song
- Format
- KORG (KROME) format, SMF format 0 and 1
Media
- Load, Save, Utility, Data filer functionality (Save and Load MIDI System Exclusive Data)
Controllers
- Controllers
- Joystick, SW [1], SW [2]
- Realtime Control
- [SELECT] Switch: REALTIME CONTROL (TONE, USER), ARP
4 Knobs; REALTIME CONTROL: Real-time Modulation, Arpeggio control
- Drum Track
- [DRUM TRACK] Switch On/Off
- Arpeggiator
- [ARP] Switch On/Off
User Interface
- Display:
- Touch view graphical User Interface
7 -inch Color TFT LCD, 800 x 480 pixel
Onboard LCD brightness control
- Mode Switch:
- [COMBI], [PROG], [SEQ], [GLOBAL], [MEDIA] Switch
- VALUE controller:
- [VALUE] Dial, [INC], [DEC] Switch, 10 key block ([0] – [9], [-], [.], [ENTER], [COMPARE])
- BANK Switch:
- [A], [B], [C], [D], [E], [F] switch (in Combination mode, [A], [B], [C], [D] switch are available)
- SEQUENCER switch:
- [PAUSE], [REW], [FF], [LOCATE], [REC], [START / STOP]
- TEMPO:
- [TEMPO] knob, [TAP] switch
- Others:
- [PAGE] switch, [WRITE] switch, [EXIT] switch, [VOLUME] knob, Contrast knob
Đầu ra
- AUDIO OUTPUT (L / MONO, R)
- 6.3mm (Mono) Phone jack, Unbalanced
Output Impedance: 1.1[kΩ] (L / Mono terminal: in case of Mono output, = 550[Ω])
Maximum level: +16.0 [dBu], Load Impedance: more than 10 [kΩ].
- Headphone Output
- 3.5mmStereo phone jack
Output Impedance: 33[Ω], Maximum level: 60 + 60[mW] (In case of 33[Ω] Loaded)
Đầu vào
DAMPER pedal (Half Damper supported)
ASSIGNABLE SWITCH
ASSIGNABLE PEDAL
Chức năng khác
- MIDI
- IN, OUT
- Cổng giao tiếp
- USB-MIDI Interface (TYPE B) x 1
- Thẻ nhớ
- Max: 2 GB / SD Memory Card is supported
Max: 32 GB/ SDHC Memory Card is supported
(SDXC Memory Card is not supported)
